• Sealed Switch Design
• UL 1081 Design
• 50°C Ambient
• 304 Bearing Shaft End
• 303 Stainless Steel Shaft
• Threaded Shaft
• Capacitor Start-Capacitor Run

Used On:

• Hayward Max-Flo SP1800X Pump Parts
• Hayward Super Pump SP1600X Pump Parts
• Jacuzzi L Series Pump Parts
• Jacuzzi P, PC, EP Pump Parts
• Jacuzzi PH and UPH Pump Parts
• Jacuzzi RC Pump Parts
• Jacuzzi Ring-Lok Pump Parts
• Jandy HHP/HHPU Pump Parts
• Speck E90 Pump Parts
• Speck ES90 Pump Parts
• Speck S90 Pump Parts
• Jacuzzi Ring-Lok R, P, PC & UP Pump Parts

Specifications:

• Phase: 1
• Output HP: 1 Hp
• Output KW: 0.75 kW
• Voltage: 230/115 V
• Speed: 3450 rpm
• Service Factor: 1.1
• Frame: 56J
• Enclosure: Open Drip Proof
• Thermal Protection: Automatic
• Ambient Temperature: 50 °C
• Frequency: 60 Hz
• Current: 7.5/15.0 A
• Duty: Continuous
• Insulation Class: B
• UL: Recognized
• CSA: Y
• Number of Speeds: 1
